FusionSolar Smart PV Solution
Huawei brings the latest digital and internet technology into commercial rooftop PV power generation.
Our solution makes any commercial rooftop PV power system more efficient and more intelligent.
Let us help you to maximise your return on investment.
Our solution makes any commercial rooftop PV power system more efficient and more intelligent.
Let us help you to maximise your return on investment.
Innovations for Lower LCOE*
String-level Management & Optimization
Fuse-free Design
Natural Cooling
Huawei-patented Smart Anti-PID
Smart I-V Curve Diagnosis
* Levelised Cost of Electricity
Your Benefits
Multiple MPPT minimize the shortcomings of shading and uneven orientations
High system availability, quick replacement and minimal power loss
Natural cooling with much lower self-energy consumption
String-level management & optimisation
Smart I-V Curve Diagnosis, online inspection across all strings
Fully sealed, IP65 prevents against water penetration and corrosion
No DC combiner boxes or fuses, minimise fire risk from DC arcing
Low noise outputs and low electromagnetic radiation fields
"0-Touch" O&M and reliable operation
Smart Inverter simplifies system architecture & design
Quick & easy construction with no Inverter housing, heavy equipment or DC combiners etc.
Smart PV Inverter
SUN2000-60KTL-M0
12 strings intelligent monitoring and fast trouble-shooting
Power Line Communication & Smart I-V Curve Diagnosis supported
Power Line Communication & Smart I-V Curve Diagnosis supported
Max. efficiency 98.9%, European efficiency 98.7% @480Vac
Max. efficiency 98.7%, European efficiency 98.5% @400Vac
6 MPPTs for versatile adaptions to different layouts
Max. efficiency 98.7%, European efficiency 98.5% @400Vac
6 MPPTs for versatile adaptions to different layouts
DC disconnect integrated; Type II surge arresters for both DC and AC
Ground fault protection; Integrated Residual Current Monitoring Unit (RCMU)
Ground fault protection; Integrated Residual Current Monitoring Unit (RCMU)
Natural cooling technology with no external fans
IP65 protection rating
IP65 protection rating
Smart PV Inverter
SUN2000-36KTL
8 strings intelligent monitoring and fast trouble-shooting
Power Line Communication (PLC) supported
Smart I-V Curve Diagnosis supported
Power Line Communication (PLC) supported
Smart I-V Curve Diagnosis supported
Max. efficiency 98.6% (@380 Vac / 400 Vac)
European efficiency 98.4% (@380 Vac / 400 Vac)
4 MPPTs for versatile adaptions to different layouts
European efficiency 98.4% (@380 Vac / 400 Vac)
4 MPPTs for versatile adaptions to different layouts
Fuse free design; DC disconnect integrated, safe and convenient for maintenance
Type II surge arresters for both DC and AC
Integrated Residual Current Monitoring Unit (RCMU)
Type II surge arresters for both DC and AC
Integrated Residual Current Monitoring Unit (RCMU)
Natural cooling technology with no external fans
IP65 protection rating
IP65 protection rating
Smart PV Inverter
SUN2000-33KTL-A
4 MPPTs for versatile adaptions to different layouts
8 strings intelligent monitoring and fast trouble-shooting
Power Line Communication & Smart I-V Curve Diagnosis supported
8 strings intelligent monitoring and fast trouble-shooting
Power Line Communication & Smart I-V Curve Diagnosis supported
Max. efficiency 98.6%, European efficiency 98.4%
4 MPPTs per unit, effectively reducing string mismatch
4 MPPTs per unit, effectively reducing string mismatch
DC disconnect integrated; Type II surge arresters for both DC and AC
Ground fault protection; Integrated Residual Current Monitoring Unit (RCMU)
Ground fault protection; Integrated Residual Current Monitoring Unit (RCMU)
Natural cooling technology with no external fans
IP65 protection rating
IP65 protection rating
Smart PV Inverter
SUN2000-12-20KTL-M0
AI Powered AFCI to proactively mitigate fire risk
Max efficiency 98.65%, European efficiency 98.3%
2 MPPT per unit, effectively reducing string mismatch
2 MPPT per unit, effectively reducing string mismatch
Inverter with no quick wear parts, failure rate < 0.5%
Built-in PID recovery for better module performance
Built-in PID recovery for better module performance
Smart Data Logger
SmartLogger1000
Modbus-TCP for connections to Huawei NetEco
IEC60870-5-104 for connections to third-party monitoring systems
USB and embedded web for data reading and software upgrade
Automatically detecting facilities and mapping RS485 addresses
Remote control of active & reactive power
I-V Curve Diagnosis supported
IEC60870-5-104 for connections to third-party monitoring systems
USB and embedded web for data reading and software upgrade
Automatically detecting facilities and mapping RS485 addresses
Remote control of active & reactive power
I-V Curve Diagnosis supported
Up to 80 inverters per SmartLogger1000
Up to 30 devices per RS485 bus
Easy to install on walls, tabletops and rails
Up to 30 devices per RS485 bus
Easy to install on walls, tabletops and rails
Max. reliable communication range of 1,000m
Smart Data Logger
SmartLogger1000A
Smart Zero Export control design
Flexible connection to NetEco1000s, FusionSolar Smart PV Management System, and third-party platform
Remote control of active & reactive power
Flexible connection to NetEco1000s, FusionSolar Smart PV Management System, and third-party platform
Remote control of active & reactive power
Convenient communication by 2G / 3G / 4G²
MBUS transmission optional
APP and embedded web for data reading and software upgrade
MBUS transmission optional
APP and embedded web for data reading and software upgrade
Improvement of safety by SPD insid
NetEco Management System
NetEco1000S
Easy data accesses on mobile devices
Proactive reports of yields and alarms
Smart String I-V Diagnosis supported
Proactive reports of yields and alarms
Smart String I-V Diagnosis supported
One-click installation on PC
Fault alarms via SMS and E-mail
Fault alarms via SMS and E-mail
Hierarchical management
Up to 25 years data storage in CSV file format
Up to 25 years data storage in CSV file format
