Input

Rated input DC power¹

600 W

Absolute max. input voltage

80 v

MPPT operating voltage range

10 – 80 V

Max. short-circuit current (Isc)

16 A

Max. efficiency

99.5%

Weighted efficiency

99.0%

Overvoltage category

Output

Max. output voltage

80 v

Max. output current

16 A

Output bypass²

Yes

Output voltage during standby per optimizer

1 v

Communication

Communication protocol

MBUS

Standards Compliance

Safety

IEC62109-1 (class II safety)

EMC

IEC61000-6-1, IEC61000-6-2, IEC61000-6-3, IEC61000-6-4, EN 55011:2016/A2:2021, EN62920:2017/A1:2021

RoHS

Yes

Fire Safety

NEC 2020

General Specifications

Dimensions (W x H x D)

73.8 mm x 145 mm x 27.2 mm

Weight (including cables)

0.65 kg

Installation part (optional)

Frame mounting bracket / T-shaped bolt³

Input connector

Staubli MC4

Input wire length

0.1 m

Output connector

Staubli MC4

Output wire length

(+)2.225 m / (-) 0.1 m

Operating temperature/humidity range⁴

–40°C to +85°C / 0% - 100%

IP rating

IP68

Compatible inverters

SUN2000-2/3/3.68/4/4.6/5/6KTL-L1, SUN2000-3/3.68/4/4.6/5/6K-LB0, SUN5000-3/6K-LB0
SUN2000-8/10K-LC0, SUN2000-3/4/5/6/8/10KTL-M1, SUN2000-10KTL-BEM1
SUN2000-5/6/8/10/12K-MAP0, SUN5000-8/12K-MAP0, SUN2000-10K-MAP0-BE
SUN2000-12/15/17/20/25K-MB0, SUN5000-17/25K-MB0

PV System Design5

PV System Design⁵

SUN2000-2–6KTL-L1

SUN2000-8K/10K-LC0

SUN2000-3–6KTL-LB0

SUN5000-3K/6K-LB0

SUN2000-3–10KTL-M1

SUN2000-10KTL-BEM1

SUN2000-5-12K-MAP0

SUN5000-8K/12KMAP0

SUN2000-12-25K-MB0

SUN5000-17/25K-MB0

Min. string length (power optimizers)

Max. string length (power optimizers)

Max. DC power per string

6000 W

12,000 W

*1 The maximum power of PV module at STC shall NOT exceed the “Rated Input DC Power” of the power optimizer. PV modules with up to +5% power tolerance are allowed.

*2 Any power optimizer, which is connected to an operating inverter in a PV string, will be bypassed when it fails.

*3 It is for PV module frame/extruded aluminum profile racking system installation.

*4 When the operating temperature of the MERC-600W-PA0 reaches 70 °C to 85 °C, it may shut down due to over-temperature protection . After the temperature decreases, it can automatically resume working without causing any damage.

*5 SUN2000-450W-P2/600W-P, MERC-600W-PA0 and MERC-1100/1300W-P can NOT be used in mixture under the same Smart Energy/PV Controller.

Disclaimer: the preceding values are measured by an internal laboratory of Huawei in a specific environment. The actual values may vary with products, software versions, usage conditions, and environmental factors.
